Introduction

PangoMicro is a subsidiary of Tsinghua Unigroup and specializes in the research, development, production, and sales of programmable logic devices (FPGAs, CPLDs, etc.). It is a leading domestic company in the FPGA industry. PangoMicro has released a full range of high, mid, and low-end products, including the Compact, Logos, Logos2, Titan, and Kosmo series, offering cost-effective CPLD/FPGA solutions. These products are widely applicable in various fields such as communication networks, information security, and industrial control. They are used for tasks like image and video processing, data analysis, network security, instrumentation, consumer electronics, drones, and industrial control.

Titan-2 Series

The Titan-2 series of FPGAs uses advanced mature technology to support high-speed interfaces and high-performance modules, suitable for high-end application requirements. It provides high-performance programmable solutions for customers and can be widely used in industries such as communication, image and video processing, data analysis, network information security, and instruments and meters.

Features:

• SERDES rate up to 13.125Gbps
• High bandwidth, supporting DDR4 1866Mbps
• Support RAM soft error detection and correction function
• Hard-core PCIe Gen3x8
• Multiple high-speed IO interfaces: LVDS, MIPI, LVDS up to 1.4Gbps
• Integrated 12-bit resolution, 1MSPS ADC hard core
• Advanced 256-bit AES encryption

Titan Series

The Titan series is the first domestically produced and independently owned FPGA product in China, using advanced mature technology and independent intellectual property architecture. It is widely used in communication networks, information security, industrial control, and other fields.

Features:

• Up to 174K equivalent LUT4 logic units
• Advanced mature technology, independent LUT5 architecture, innovative software and hardware integrated development process
• The system's highest frequency is 500MHz, and the block memory resources are up to 9Mbit
• Supports multiple high-speed IO interfaces: SERDES rate of 5.0Gbps, DDR3 rate of 800Mbps, LVDS rate of 800Mbps, and PCIE Gen2x4

Logos-2 Series

The Logos-2 series of FPGAs uses advanced mature technology, with logic unit scales ranging from 25K to 200K, providing rich on-chip resources and high-performance interfaces, supporting high-speed SERDES, PCIe Gen2, DDR3, and other features. Compared with the previous generation, performance has increased by 50%, and power consumption has decreased by 40%. It is suitable for large-scale, low-power, and high-performance application requirements, widely used in communication, video and image processing, industrial control, medical, and consumer electronics fields.

Features:

• 25K~200K LUTs
• Flexible configurable logic modules (CLMs), each CLM contains 4 LUT6 and 8 registers
• Highest support for 6.6Gbps SERDES
• Hard-core PCIe Gen2x4
• DDR3 supports a maximum rate of 1066Mbps
• Supports RAM soft error detection and correction function
• Flexible IO interfaces, providing LVDS, MIPI, TMDS, etc., with LVDS up to 1.25Gbps
• Integrated 12-bit resolution, 1MSPS ADC hard core
• Advanced 256-bit AES encryption

Logos Series

The Logos series of FPGAs uses advanced mature technology and a new LUT5 structure, integrating RAM, DSP, ADC, Serdes, DDR3, and other rich on-chip resources and IO interfaces. It has low power consumption, low cost, and rich functions, providing customers with high-cost-effective solutions. It is widely used in industrial control, communication, and consumer electronics fields and is an ideal choice for customers' large-scale, cost-sensitive projects.

Features:

• Advanced mature technology, low cost, and low power consumption
• 12K~100K LUTs
• Flexible programmable CLMs, each CLM contains 4 LUT5 and 6 registers
• Supports RAM soft error detection and correction function
• Provides DDR3 800Mbps
• Supports multiple standard IO interfaces, LVDS, MIPI interfaces
• LVDS rate up to 800Mbps
• SERDES rate up to 6.375Gbps
• Integrated ADC hard core
• Advanced 256-bit AES encryption

Compa Series

The Compa series of CPLD products use mature technology and independent intellectual property architecture to meet the requirements of low power consumption, low cost, and small size design. It is suitable for system configuration, interface expansion and bridging, board-level power management, power-on timing management, sensor fusion, and other application requirements, widely used in communication, consumer electronics, drones, industrial control, and other fields.

Features:

• Advanced mature technology, non-volatile programmable device
• 1K~10K LUT4 logic units, supporting 3.3/2.5V core or 1.2V low-voltage core
• Supports MIPI, LVDS, I2C, SPI, OSC, RAM, PLL, etc.
• Supports RAM soft error detection and correction function
• Supports Dual Boot function, no external Flash required
• Supports background update, disable readback and other functions, high security
• Up to 384 user IOs
• Package as small as 2.5mm x 2.5mm
